WAY JET MACHINE TOOLS CO., LTD.

Spindle shaper head, X & Y axes motion on head, fixed bed; for automotive pplications and other small bore machining on sheet metal molds/dies

Precision servo motors on X, Y, Z axes provide excellent stability during drilling

1μ optical scale, linear slideway and ballscrew ensure very accurate movements

Automatic copper tube deviation correction

Reads NC programs, G code and DXF files; automatically finds starting point before beginning maching process

Machining coordinates may be editted directly when NC programming is not available

Automatically finds edge, ID and center positions

Coordinates can automatically rotate to any angle

Mirror image function

Range of hole diameters:0.3-3.0 mm

Automatic color display of current and next drilling positions

Z axis auto reset and depth calculation. Z axis automatically checks depths of holes, and returns to complete any that are too shallow.

Date input by USB, or network.

Easy to learn dialog interface operation

Suitagle for larger work-piece and plastic mold.

Drilling can enter material at angle, into curved surfaces, irregular shapes.

Precision servo motor control allowing drilling stable.

Designed for drilling in hardened tool steel, carbides and other conductive materials.

Drilling capacity from 0.2mm to 3.0mm diameter brass or copper electrode tubes.

The flushing medium used by this machine is distilled water and environment friendly.

Automatic pressure release function is used in the system.

Worktable is made of stainless steel to maintain longer life.

Precision servo motors on X,Y,Z axes provide excellent stability during drilling

X,Y axes provide 1μ optical scale and ballscrew ensure very accurate movements

NC prpgram G-code and DXF files could be directly read; Automatically finds the start cutting point and begins a fine hole drilling process.

The machining coordinate can be input directly when NC program is not available.

Automatic edge, internal diameter finding, and centering.

Coordinates can rotate at any angle

Mirror image function.

Drilling capacity from 0.3～3.0 mm

Automatic illustrates the path of current and next drilling positoion with color.

Z axis auto reset and depth calculation. Z axis automatically checks depths of holes, and returns to complete any that are too shallow.

Data could be input by USB, or network.

Direct and easy learning dialogue operation interface.
